Architecture

The Living Blueprint

End-to-end view of all seven layers — from EHR data sources through ingestion, stream processing, storage, AI inference, and client surfaces. Includes the full technology stack with AWS + Snowflake recommendations.

Full Platform Architecture

End-to-end view of all seven layers — from EHR data sources through ingestion, stream processing, cloud-agnostic storage, AI/ML inference, REST API, and client surfaces. Hover any node for details.

Ingestion / messaging

Processing

Storage

AI / ML

API layer

Clients

Bring Your Own Data Platform

ℹAll services are cloud-agnostic. Swap any layer by changing a single .env variable — no code changes required.

ⓘBring Your Own Data Platform: Patient360 deploys its Bronze/Silver/Gold models and dbt transformations directly into the customer's existing Snowflake, Databricks or BigQuery warehouse — no isolated clinical-data silo. Real-time HL7/FHIR clinical feeds land alongside the customer's existing claims, operational and SDoH data, so the Patient 360 combines live and historical data in one governed model the customer already owns.
